NEWS
APRIL
We look forward to seeing you at the MiningWorld Russia 2023 exhibition!
From April 25 to 27, 2023, our company will take part in the 27th International Exhibition of Machinery and Equipment for Mining, Processing and Transportation of Minerals.
We invite you to visit our booth №C4103 in Hall №3, Pavilion №1, Crocus Expo IEC, Moscow.
At the exhibition, our company will present:
- Pumping unit "Umka"
- Hummer crusher
Our specialists will be happy to advise you and answer any questions.
Using our promo code mwr23eMARR, you can get an e-ticket for free on the website of the organizer of the exhibition. Without using a promo code, visiting the exhibition is paid.
To get a free entrance ticket for the expo MiningWorld Russia
See you at our booth №C4103 from April 25 to 27, 2023 at the Crocus Expo IEC!
JANUARY
MASHKHIMPROM LLC has manufactured and conducted tests for tightness and strength of the surface condenser for Silvinite Processing Plant of PU4
The surface condenser is designed for heating the uterine lye as part of a vacuum crystallization plant with controlled crystal growth for the crystallization of potassium chloride.
Main technical characteristics:
length - 7500 mm
diameter - 1600 mm
number of tubes - 900
weight - 11 tons
material - Titanium "Grade 1"
DECEMBER
ДЕКАБРЬ
We manufacture a set of powered roof support sections with linear expansion 09/15 for seams with a small removable thickness of 1.15-1.45 m:
The mechanized support will be operated as part of a mechanized complex designed for ore extraction.
Mechanized support provides control of the roof in the stope and maintains it in a safe condition for the movement of personnel and equipment in the process of ore mining.
Main technical characteristics:
folded height - 900 mm
extended height - 1500 mm
top width - 1700 mm
section weight - 5870 kg
DECEMBER
NOVEMBER
It’s our 15th birthday!
For 15 years, MASHKHIMPROM has grown from a small company into a giant in the production of non-standard equipment and technological systems for the mining, chemical and oil industries, and has become a reliable partner in the production of construction and installation works and installation of metal structures. Throughout the time, we have been conquering the international and domestic markets not with the scale of production, but with quality!
APRIL
A horizontal centrifuge with a pulsating piston CPU-50 was designed and manufactured.
The pulsating centrifuge of the CPU-50 type is a filtering, two-stage, continuous operation. Designed to separate the product into solid and liquid phases under the influence of centrifugal force (dehydration).
The pulsating centrifuge is a stator, which is an oil tank, on which the bearing housing with the rotor shaft, pusher rod and bearings, the rotor drive and the hydraulic system are located. The technological chamber of the centrifuge consists of two perforated baskets, internal and external, in which slotted sieves are installed as a filter element. Baskets are located inside the casing, which is divided into several zones.
All parts of the centrifuge in contact with solid and liquid phases are made of stainless steel.
Main technical characteristics:
drum execution: 2-stage
drum diameter: 1120/1200mm
maximum rotor speed: 1000 rpm
pulsation frequency: 65/75 strokes/min
productivity (dry): not less than 50 t/h
product temperature: 26-50°С
overall dimensions WxHxL: 2280x1900x4430 mm
APRIL
We have made acceptance and started shipping the sets of the mechanized support section for the lava complex No. 3n-1 of the Berezovsky mine 1 PU JSC Belaruskali with an average take-out capacity of 2.35 - 2.4 m in the following compositions:
linear section of powered support with extension 16/25
powered support for end section with extension 16/25
coupling powered support with extension 16/25
MARCH
A screw mixer designed for the treatment of potassium chloride with reagents at SOF 4PU of JSC "Belaruskali" was manufactured and presented to the commission of JSC Belaruskali.
Brief technical characteristics:
fabrication material: 10Х17Н13М2Т
capacity: 300 t/h
overall dimensions: 1500 x 1200 x 6260mm
spiral diameter: 900mm
FEBRUARY
We manufacture cargo and passenger modules of mining machines for the mechanical repair shop of JSC Belaruskali.
BelKa-018A 5M for the transportation of operating personnel - 26 pcs.
BelKa-018A GL cargo-passenger version - 17 pcs.
From February to April, 14 modules for mining machines "BelKa" were manufactured and shipped.
MAY
We manufacture a screw solvent with a dewatering Elevator designed for mixing silvinite ore with a dissolving lye, leaching potassium chloride from it and dewatering halite waste as part of a 900t/h processing line.
Parameter
Screw solvent
Dehydrating elevator
Performance:
by solid phase, t/h
900
900
by liquid phase, m3 / h
1700
-
Working pressure
for the filling
for the filling
Operating temperature, °C
95±3
95±3
Density of the dewatered halite dump in the elevator, kg / m3
1500
Degree of elevator's buckets filling, %
up to 85
Mass fraction of water in the dehydrated product, %
8÷14
Drive gear
ЦДН-710-50-33-ЦвхЦвых-У3
7Ц3-1505-80-33-ЦвхЦвых-У5
Electric drive motor
АОЗ-400М-8 У2 IM1001
АИР315М8 IM1001
The number of revolutions of the electric motor, rpm
750
750
Electric motor power, kW
250
110
V-belt transmission ratio
1,562
1,336
Operating part
Rotor
Bucket chain
Rotor length, mm
27760
Rotor mass, kg
29480
Rotor diameter, mm
3233
Rotor speed, rpm
6
Quantity of bucket, piece
44
Volume of a bucket, l
320
Weight of bucket chain, kg
20350
Linear speed of the bucket chain, m / s
0,58
Overall dimensions of the screw solvent with a dehydrating elevator:
length, mm
30298
width, mm
16855
height, mm
16392
Weight of screw solvent with dehydrating elevator, kg
259344
Noise level (max), dB
80
Service life of a screw solvent with a dehydrating elevator, years
11
Operating mode
Continuous
OCTOBER
The construction of the Belkali-MIGAO potassium nitrate production plant has been completed.
СЕНТЯБРЬ
On September 27, Prime Minister of Belarus Sergei Rumas visited MASHKHIMPROM LLC.
Prime Minister Sergei Rumas visited MASHKHIMPROM. The head of the Government was introduced to the production complex and told about the results of financial and economic activities.
MASHKHIMPROM LLC specializes in projecting, manufacturing, assembling of supporting steel fencing constructions and non-standard equipment for chemical, petroleum and mining industry.
The director of MASHKHIMPROM LLC Alexey Rabotayev tells:
— The main feature of our production is difficult and very labor-intensive technological process. It does not love fast paces and is difficult in welding as there are several modes of welding production. The equipment from titanium which we make is used in aggressive environments, and it allows our products to be resistant to abrasion. Today we have two production cases and if everything safely develops, then we will construct also the third, we will increase quantity of jobs by 30 — 50 specialists and, of course, we will buy the new equipment.
During the inspection of MASHKHIMPROM production Ivan Golovaty, General Director of Belaruskali, noted the uniqueness of ITS work:
— Today the enterprises are or vendors of some certain nodes, details, or the enterprises which release the equipment in a complex. Uniqueness of MASHKHIMPROM, in my opinion, that it is also the organization which performs installation and construction works because today each element of the equipment for its subsequent mounting is considered. And it allows including to reduce terms which are spent for mounting.
Speaking about MASHKHIMPROM, we cannot but mention the construction of a new plant for the production of potassium nitrate, as MASHKHIMPROM is the general contractor for the construction of a joint Belarusian-Chinese enterprise. Ivan Golovati explains:
- By the end of September we plan to finish the main installation and construction works. And in early October start commissioning works, after which the plant will be put into operation. Today, construction is carried out according to the Chinese project and using Chinese technologies. It was planned that some of the equipment would be supplied from China, it is about 40 - 50%, but in fact, taking into account the time frame at which we are building the plant, even Chinese colleagues did not have time to supply us with the necessary equipment. And here we were very helped by MASHKHIMPROM - the necessary parts from stainless steel, titanium were quickly created. And in general the construction takes place very quickly: from the planned 36 months the plant was built in a year.
The construction of this plant is very important for the industrial complex of Belarus, as the production of new potassium nitrate, including import substitution for the Republic of Belarus, will begin. At the first stage production will be about 80 thousand tons, at the second stage - 160 thousand tons. Potassium nitrate supplies are planned to Europe and China. After the project is fully implemented and production reaches 160 thousand tons, it will be about 5% of the world 's potassium nitrate production capacity.
Source: Издательский дом «Беларусь Сегодня»
Photo: Максим Гучек, БЕЛТА.
AUGUST
We are building a plant for the production of potassium nitrate with a capacity of 160 thousand tons per year
A new high-tech production is being prepared to be launched this year near Soligorsk. Our country will launch the production of chlorine-free potash fertilizers - without them, for example, it is difficult to imagine a good potato harvest. The product is in demand both in the domestic market and abroad. Deliveries are planned to the EU countries, Russia, Turkey. Read more about this in the plot of the TV channel "Belarus-1".
JULY
Powered roof supports "МХП-16/25» for mine lava "Б2-н-1» JSC Belaruskali (SPF-4PU) has been produced.
Mechanized support ensures the management of the roof in the clearing bottom and on the interfaces with drifts and maintaining it in a safe condition, fixing the lava depending on the adopted technological scheme for working off the clearing column.
The mechanized support will be operated as part of the mechanized complex, which is a combination of machines and mechanisms united by a common technological scheme, and intended for the extraction of ore in lava with a pillar system of development of a potash reservoir with a long clearing face. Output power - 1.9-2.45m.
The support section is supportive and protective, has a sliding width of 1600-2500 mm, an installation step of 1.75 m.
JULY
The pressure vessel “Secondary vapor condenser CO201” was manufactured, tested and submitted to the acceptance commission of Belkaliy-Migao LLC
The condenser is produced for the object “Plant for the production of potassium nitrate at the industrial site of the 4PU, JSC Belaruskali”.
Specifications:
diameter - 1000 mm
length - 5400 mm
type - horizontal arrangement surface heat exchanger, shell-and-tube construction (tube Ø25x2 in the amount of 660pcs)
number of moves – 4
heat exchange surface - not less than 205 m2
material - AISI 316L stainless steel
OCTOBER
Construction of a new production building has been completed
he new production building with an area of 2448 m2 will increase the volume and improve the quality of products through the introduction of flexible robotic production modules, the organization of flexible automated production sites using the latest metalworking world brand equipment . It will also provide an opportunity to master the production of new equipment.
We are focused on the quality of our products therefore at each stage of production we strive to reduce the human factor to a minimum.
The new production building has a painting and drying chamber "C-PRO" with dimensions of 10x6x4 meters which will allow to prepare and paint the surfaces in accordance with the requirements of international standards.
The existing production plant, administrative buildings were additionally externally updated.
AUGUST
Solvent screw with elevator dewatering unit is complete.
The equipment has been delivered with a test assembly to the customer
silvinite processing factory 4PU JSC Belaruskali
Screw solvent with elevator dewatering unit as part of the production line is intended for leaching of potassium chloride from sylvinite ore. It consists of an auger solvent and a dewatering elevator.
Brief specifications:
operating temperature - up to 118 ºС
productivity - 800 t / h
overall dimensions - 29,8х15,1х16,6 m
material of the equipment - 1.4462 according to STB EN10088-2-2009
weight - 215 tons
APRIL
We manufactured a surge tank with a control assembly and handed over to the Customer JSC Belaruskali (SPF-4PU) 29.13.13.115.00.00.000 from titanium
The surge tank is designed to distribute the flow of saturated lye evenly to the Brandes type sedimentation tanks with the possibility of rate control.
The surge tank is installed in the existing chain of devices, taking into account their mutual arrangement without any changes in the technological process. The device is installed instead of worn out one.
Brief specifications:
diameter - 2 000 mm
height - 3200 mm
weight - 3300 kg
operating temperature - 105 ºС
material - Titanium "Grade 1"
MARCH
The project for NPO PASSAT LLC has been completed
We have produced four vertical surface condensers for vacuum crystallization setting with controlled crystal growth for crystallization of potassium chloride made of titanium Grade 1 at the silvinite processing factory 4 PU, JSC Belaruskali.
The surface condenser is designed for heating the uterine lye as part of a vacuum crystallization plant with controlled crystal growth for the crystallization of potassium chloride.
Lye feeds through the pipe space from the pump, through the intertubular space parallel steam is supplied. In the implemented scheme of the external counterflow, the process of heat transfer from the steam to the lye takes place, as a result of which the lye is heated up to a temperature of 63.9 °C.
Brief specifications:
outer diameter of the body - 2000 mm
length of the cylindrical part of the body - 10000 mm
number of tube bundle tubes - 2500 pcs. with the method of installation
rolling + welding
execution of covers - spherical
weight - 20 000 kg
SEPTEMBER
The equipment for technical re-equipment of the vacuum-crystallization setting of the silvinite processing factory 4 PU, JSC Belaruskali
We have mastered the chemical-technological heat-exchange equipment - a heat exchanger made of titanium of 10 meters length and 2 meters in diameter.
The surface condenser is designed for heating the uterine lye as part of a vacuum crystallization plant with controlled crystal growth for the crystallization of potassium chloride.
Lye feeds through the pipe space from the pump, through the intertubular space parallel steam is supplied. In the implemented scheme of the external counterflow, the process of heat transfer from the steam to the lye takes place, as a result of which the lye is heated up to a temperature of 63.9 °C.
Краткое описание оборудования:
1 – distribution camera
2 – heat exchange chamber
3 – the camera cover
4 – fixed support
5 – mobile support
MASHKHIMPROM - QUALITY WITHOUT COMPROMISE!
